Protective Caps

MS27510 and MS27511
Protective Covers
MIL-C-38999
Series II

TABLE I
Shell
Size
G Dia
Max
H Dia
Max
J Nom
Length
K Dia
Min
8 .720 (18.3) .630 (16.0) 3.00 (76.2) .890 (22.6)
10 .850 (21.6) .761 (19.3) 3.00 (76.2) 1.010 (25.7)
12 1.000 (25.4) .936 (23.8) 3.00 (76.2) 1.140 (29.0)
14 1.130 (28.7) 1.074 (27.3) 3.50 (88.9) 1.260 (32.0)
16 1.250 (31.8) 1.172 (29.8) 3.50 (88.9) 1.390 (35.3)
18 1.380 (35.1) 1.304 (33.1) 3.50 (88.9) 1.510 (38.4)
20 1.500 (38.1) 1.435 (36.4) 4.00 (101.6) 1.640 (41.7)
22 1.630 (41.4) 1.560 (39.6) 4.00 (101.6) 1.760 (44.7)
24 1.750 (44.5) 1.688 (42.9) 4.00 (101.6) 1.890 (48.0)

1. For complete dimensions see applicable Military Specification.

2. Metric dimensions (mm) are indicated in parentheses.

Set Ascending Direction
View as Grid List

3 Items

per page
  1. In stock
    was $56.280 Special Price $28.140
    EA
    Add to Wishlist
  2. In stock
    PROTECTIVE CAP SHELL SIZE 22
    Part Number : MS27511F22A
    was $76.000 Special Price $38.000
    EA
    Add to Wishlist
  3. In stock
    PROTECTIVE CAP SHELL SIZE 24
    Part Number : MS27511F24A
    was $76.000 Special Price $38.000
    EA
    Add to Wishlist
