Deutsch HD30 series 19 way jam nut receptacle connector housing.
- Number of Positions: 19
- 13 X size 16 contacts 20-14 ga 13 amp max per contact
- 6 X size 12 contacts 14-10 ga 25 amp max per contact
Additional parts will be required to assemble this connector, not included in price of HD34-24-19PN
Required/Additional Components
- (1) Panel nut
- (1) Lock washer
- (13) size 16 male (pin) contacts
- (6) size 12 male (pin) contacts
Dimensions
- Mounting Hole: 1.579"
- Overall Length: 1.647"
- Overall Diamater: 2"
See related items and mating connector tabs below for more information
