MS24523-23 Mil-Spec ON-ON Sealed Switch SPDT 1TL1-3

The Honeywell Micro Switch MS24523-23 TL series toggle switch is an ideal switch for demanding applications, compliant to MIL-DTL-3950, this high performance switch is a logical choice for use in environments where sealing and resistance to shock and vibration are required. The MS24523-23 is particularly suitable for applications in off-highway, aviation, commercial and industrial equipment. This compact, environmentally sealed switch is available in single and double pole configurations.

Switch Operation:

With the switch mounted with the keyway facing in any direction, The switch acts as an ON-ON switch that is Latched ON in the opposite direction of the keyway. Refer to the circuit diagram below for wiring specifics.

Common Uses:

• Multiple Ignition boxes
• A/B controls
• Weapons systems
